Paint + Coating for Stainless Steel in Food / Pharma Plants — FDA 21 CFR + ISO 22196 + TIS spec

See the whole-system guide: the Food & Cold-Chain plant fit-out guide — this article is one step — see the end-to-end fit-out guide.

Food and pharmaceutical (food + pharma) plants in Thailand must pass HACCP, GMP, ISO 22000, FDA Thailand, and the regulatory requirements of export countries — and among these, surface coating is a point of rigorous inspection, because:

1. Food contact surface comes into direct contact with raw materials — there must be no migration of chemicals from the paint
2. CIP (Clean-In-Place) chemistry — caustic NaOH 2-4% + acid 1-2% + sanitizer (PAA, ClO₂) → destroys ordinary paint
3. Biofilm prevention — stainless structures with pits or scratches become accumulation points for Listeria, E. coli, and biofilm
4. Audit traceability — FDA + EU regulators require a Certificate of Compliance (CoC) for every lot of paint

Not every paint can be used — ordinary industrial paints (construction epoxy paint, alkyd, latex) do not pass FDA and will migrate into raw materials in the first CIP cycle

This article summarizes:

1. Why stainless 304/316L still needs coating — the pit + biofilm problem
2. Standards that must be met — FDA 21 CFR 175.300, ISO 22196, TIS (มอก.) 1521
3. SAHA SKUs that meet the standards — 2-part solvent-free food-grade epoxy, acrylic-silicate antimicrobial concrete sealer
4. DFT (Dry Film Thickness) + application + QC

Why Stainless Still Needs Coating

Pit Corrosion That Pickling Does Not Cover

Stainless 304L (Cr 18% Ni 8%) and 316L (adding Mo 2% for chloride resistance) undergo a pickling + passivation process at the factory to form a surface oxide layer (Cr₂O₃) — but at points such as:

• Welding HAZ — heat affected zone after welding where chromium is drawn out
• Cold-formed corners — curved corners with high surface strain
• Mechanical scratch — from installation or tool drop
• Crevice in flange / gasket — standing water

pit corrosion at the μm-mm scale will occur — taking up chloride from CIP cleaning + saltwater residue → becoming a permanent corrosion point

Coating role: seal the pit + crevice surface before biofilm formation, creating a chemical barrier between the stainless and the environment

Biofilm Prevention

The smooth surface (Ra <0.8 μm) of stainless looks clean — but at the 0.5-1 μm scale there is surface roughness where bacteria attachment forms within 24-72 hours → multilayer biofilm → accumulation point for Listeria / Salmonella / Pseudomonas → audit fail

Antimicrobial coating (ISO 22196 certified) contains silver ion (Ag⁺) or zinc-pyrithione (ZnPT) that releases continuously → kills bacteria at the surface → reduces biofilm rate 99%+

Standards That Must Be Met

Standard	Inspection point	Test method
FDA 21 CFR 175.300	Resin + monomer in the paint must not migrate beyond limit	Extractive test: 8% ethanol + 50% ethanol + n-heptane + water 120°F × 24 hr
EU 10/2011	Overall migration limit OML ≤ 10 mg/dm²	EN 1186 test
ISO 22196	Antibacterial activity R ≥ 2.0 (log reduction)	E. coli + S. aureus inoculation 35°C × 24 hr
NSF/ANSI 51	Food equipment material — finished surface	NSF protocol
TIS มอก. 1521-2541	Thai paint — heavy metal limit + food contact	TIS extractive test
HACCP / GMP	Process control + supplier traceability	Manufacturer must submit CoC + COA for every lot

Tip: Choose a paint with a CoC from a manufacturer that specifies FDA 21 CFR 175.300 + EU 10/2011 + ISO 22196 — covering all the main audits of a food/pharma plant.

SAHA SKUs for This Application

2-Part Solvent-free Food-Grade Epoxy

• Application: food contact area, water-immersed surface, CIP-resistant
• FDA 21 CFR 175.300: ✓ certified
• VOC: Zero VOC (FDA compliance)
• DFT recommended: 400 μm in two coats (200 μm × 2 layers)
• Cure: at 25°C — 8 hr recoat, 7 days full cure
• Substrate: stainless 304/316L, mild steel pre-treated, concrete (food production floor)
• Pack: 4L kit (3L A + 1L B), 20L kit

Acrylic-Silicate Antimicrobial Concrete Sealer

• Application: floor + wall (food production area), antimicrobial surface
• ISO 22196 Activity: R ≥ 3.0 (99.9% bacteria reduction E. coli + S. aureus)
• Service life: 3-5 years antimicrobial activity
• DFT: 150-200 μm
• Substrate: concrete (food plant floor), painted surface (over the food-grade epoxy)
• Pack: 4L, 20L

Combo Recommendation — Production Hall Floor

Layer 1 (Primer): 1-part moisture-curing PU primer @ 150 μm
Layer 2 (Topcoat 1): 2-part food-grade epoxy @ 200 μm
Layer 3 (Topcoat 2): 2-part food-grade epoxy @ 200 μm
Layer 4 (Sealer): acrylic-silicate antimicrobial sealer @ 150 μm
Total DFT: ~700 μm
Service life: 8-12 years (heavy traffic), 12-20 years (light traffic)

DFT — Choose by Exposure

Application	DFT	Coating spec	Re-paint cycle
Storage tank — dry food contact	200 μm	food-grade epoxy × 1	10-15 years
Mixing vessel — wet + chemical	400 μm	food-grade epoxy × 2	5-8 years
Production floor — light traffic	500-700 μm	PU primer + food-grade epoxy × 2 + antimicrobial sealer	8-12 years
Production floor — heavy traffic + forklift	800-1000 μm	PU primer + food-grade epoxy × 3 + antimicrobial sealer	5-8 years
Cold storage wall (4°C / -18°C)	300 μm	food-grade epoxy + antimicrobial topcoat	8-12 years
Pharma clean room (GMP-D)	400 μm	food-grade epoxy × 2	5-7 years (per audit cycle)

Application Procedure (for contractor / TOR)

Surface Preparation

1. Degrease: FDA-compliant alkaline cleaner → rinse until pH neutral
2. Mechanical prep: SSPC-SP10 near-white blast (for steel) or SSPC-SP1 + abrasive scrub (for stainless)
3. Surface profile: 25-50 μm (Ra) with hardness Rockwell C 60 + grit
4. Final clean: wipe down with 70% IPA before applying primer

Application

1. Mixing ratio: per manufacturer (parts A + B mixed at the specified ratio) — pot life 30-45 minutes
2. Application method: airless spray (best) — pressure 2,500-3,500 psi, tip 17-21 thou
3. Recoat window: 4-8 hr (before curing to "hard dry")
4. Cure environment: clean room 18-30°C, RH < 80%, no contamination during cure

QC + Documentation

• DFT measurement: every 10 m² with an ASTM D7091 magnetic gauge — record min/max/avg
• Pinhole test: ASTM D5162 holiday detector — 5V/μm DFT
• Adhesion test: ASTM D4541 pull-off — minimum 5 MPa
• Documentation: CoC + COA + DFT report + holiday test report submitted to QA / quality manager

TOR Template for Food / Pharma Plants

1. Scope of work: paint application — surface preparation + 3-coat system for
   [Production hall floor / Mixing tank interior / Pharma clean room wall]
   total area [N] m²

2. Standards that must be met:
   - FDA 21 CFR 175.300 (resin + monomer migration)
   - ISO 22196:2011 (antimicrobial R ≥ 2.0)
   - TIS มอก. 1521-2541
   - or an equivalent standard from EU, NSF, JFRL

3. Coating system:
   - Primer: 1-part moisture-curing PU (ASTM B117 salt spray ≥ 2,000 hr)
   - Topcoat: 2-part solvent-free epoxy food-grade FDA
   - Optional sealer: acrylic-silicate antimicrobial ISO 22196
   - Total DFT: [200-1000 μm per application]

4. Documentation per delivery batch:
   - CoC + COA per pail
   - MSDS / SDS Thai + English
   - FDA + ISO 22196 certificate (3rd-party lab)
   - DFT measurement report (ASTM D7091)
   - Holiday detection report (ASTM D5162)
   - Adhesion pull-off ≥ 5 MPa (ASTM D4541)

5. Warranty: 5 years (light traffic) / 3 years (heavy traffic) — coating system
   with service-call if a crack or delamination occurs within the warranty

6. Disposal: used thinner oil + containers → through a DIW-licensed waste contractor
   invoice + manifest returned to the client

Choosing a Painting Contractor

The minimum a contractor must have:

1. Training certificate from the paint manufacturer
2. Food/pharma plant experience — show references for 3+ projects
3. DFT gauge + holiday detector + adhesion tester
4. Team > 4 people — able to run continuous shifts during shutdown
5. Worker comp + product liability insurance

SAHA Engineering Service: takes on design + spec + contractor supervision + final QC — for plants without an in-house coating team

---

This article is reference information for procurement + engineering — for GMP-A/B clean room work requiring specific migration testing, or NSF Foodzone-certified coating, contact the Sahawatthanakit (1988) engineering team for an on-site survey + spec recommendation
