Industrial Cooling Tower Selection + Water Treatment: Types, Range/Approach, and Scaling/Corrosion/Legionella Control per CTI/ASHRAE 188 for Thai Plants

A cooling tower installed and commissioned, but the leaving-water temperature never reaches target — the chiller draws far more electricity than expected — fill and nozzles foul within a year — white scale deposits appear throughout the system — or a nearby facility has suffered a Legionella outbreak. These are almost never a "bad tower." In nearly every case, the root cause is a cooling tower that was mis-specified from the start or one that has no real water treatment and Legionella management programme: wrong type selected, thermal duty calculated at the wrong wet-bulb, no structured water treatment, or no written Legionella Water Management Plan.

A cooling tower is a core plant utility that directly affects chiller COP and employee health. This article is for anyone deciding to purchase or upgrade an industrial cooling tower: select the right type → calculate Range/Approach from Thailand's actual wet-bulb → build a water treatment programme from Scaling/Corrosion through to Legionella per CTI/ASHRAE 188

This article focuses on cooling towers (open/closed) for chiller and process cooling systems. For selecting a direct refrigeration cold-room system, see Industrial Cold Room: Chiller vs Freezer vs Blast Freezer. For choosing between Glycol Chiller and DX cooling, read Glycol Chiller vs DX System for Food Processing Plants.

1. Three Main Cooling Tower Types — Wrong Choice Affects the Entire Project

Open-Circuit vs Closed-Circuit

Counterflow vs Crossflow

• Counterflow: water falls from the top while air rises upward against the flow. Highest heat-transfer efficiency, smaller footprint, but the tower is taller and slightly more difficult to access for maintenance.
• Crossflow: water falls from the top while air flows horizontally through the sides. Easier to install and better suited to height-restricted sites, but the same thermal duty requires a larger plan area than counterflow.

Induced-Draft vs Forced-Draft

• Induced-Draft (fan on top): fan draws air out through the top. More even air distribution, less hot-air recirculation — the standard configuration in the Thai market.
• Forced-Draft (fan at bottom): fan pushes air upward from the bottom. Motor is in a dry location and easier to service, but carries a higher risk of hot-air recirculation and less uniform air distribution.
• Natural Draft: no mechanical fan; relies on the buoyancy of hot air inside the tower. Used only in very large power-station cooling towers (hyperboloid structures) and is not applicable to typical Thai industrial plants.

2. Calculating Range and Approach — The Foundation of Sizing

Before selecting a type and size you must clearly define these two parameters; they govern every downstream design decision.

Range (°C) = T_hot_in − T_cold_out

Approach (°C) = T_cold_out − WBT_design

where WBT_design = Design Wet-Bulb Temperature at the installation site.

Key rules about Approach:

• The smaller the Approach, the closer the leaving-water must get to the wet-bulb limit — this requires a larger tower, stronger fans, or more fill — and cost rises steeply.
• An Approach below ~2.8°C is rarely economical: tower size increases dramatically as Approach decreases toward that threshold.
• A wider Range (more cooling per unit of circulation flow) allows a smaller tower at the same Approach, but may require deeper fill sections.

The most common and costly mistake: specifying from a European catalog at WBT 20–22°C instead of Thailand's 27–28°C

A tower rated to achieve a 4°C Approach at 22°C wet-bulb will only achieve perhaps an 8–10°C Approach at 28°C wet-bulb — meaning the leaving-water is 4–6°C warmer than targeted. The downstream chiller's COP drops measurably and electricity bills climb accordingly.

Worked comparison:

Suppose the design requires leaving-water at 32°C at a site wet-bulb of 28°C → required Approach = 32 − 28 = 4°C. A tower specified only at a European wet-bulb cannot confirm it achieves 4°C Approach in Thailand. Always demand a thermal performance curve from the supplier validated at WBT = 28°C.

3. Decision Map: Select Type + Verify Water Quality

flowchart TD
    A["Define Heat Duty (kW)
+ T_hot_in / T_cold_out target
+ WBT design 28°C (Thailand)"] --> B{"Must cooling water remain
clean and uncontaminated?"}
    B -->|"Yes — hydraulic oil
flammable fluid
special process"| C["Closed-Circuit
Fluid Cooler
sealed coil separates process fluid"]
    B -->|"No — chiller condenser
HVAC / general process"| D["Open-Circuit
Evaporative Tower"]
    D --> E{"Is installation height
restricted?"}
    E -->|"Height not a constraint"| F["Counterflow Induced-Draft
— highest efficiency, small footprint
Thai industrial standard"]
    E -->|"Height restricted"| G["Crossflow Induced-Draft
— needs more plan area
but lower overall height"]
    F --> H{"Makeup water quality:
high TSS or biological load?"}
    G --> H
    H -->|"Good makeup water
low TDS"| I["Film Fill
highest thermal efficiency
requires controlled WTP / LSI"]
    H -->|"Turbid water
high SS"| J["Splash Fill
fouling-tolerant
easier to clean"]
    I --> K["Develop Water Management Plan
per ASHRAE 188
+ CTI ATC-105 acceptance test"]
    J --> K
    C --> K

4. Evaporation, Makeup, and Blowdown — Calculating Water Consumption

Quantifying water losses from the cooling tower is fundamental both for supply planning and for designing the water treatment system.

Core equations:

Evaporation (E) ≈ 1% of circulation flow rate per ~5.5–7°C of Range

Drift (D) ≈ 0.001–0.005% of circulation flow (with modern drift eliminators)

Blowdown (B) = E ÷ (COC − 1)

Makeup (M) = E + D + B

COC (Cycles of Concentration) ≈ circulating conductivity ÷ makeup conductivity = M ÷ B

Worked numerical example:

Assume a 1,000 kW heat-rejection cooling tower, hot water 37°C in / 32°C out (Range = 5°C), circulation flow rate ≈ 172 m³/hr.

• Evaporation: ≈ 1% × 172 m³/hr × (5 ÷ 5.5) ≈ ~1.6 m³/hr
• Drift: ≈ 0.002% × 172 ≈ ~0.003 m³/hr (negligible with modern drift eliminator)
• Assume COC = 4: Blowdown = 1.6 ÷ (4−1) ≈ 0.53 m³/hr
• Makeup = E + D + B ≈ 1.6 + 0.003 + 0.53 ≈ 2.13 m³/hr (≈ 51 m³/day at 24-hour operation)

These figures are an illustrative estimate — real calculations require site psychrometric data, operating hours, and a COC target derived from makeup water analysis.

Effect of COC on water consumption and scaling risk:

5. Water Treatment — Guarding Against the Three Mechanisms That Destroy Towers

flowchart LR
    A["Circulating water
in Cooling Tower"] --> B["Scaling
CaCO3 / MgSO4 deposits
clog fill and piping"]
    A --> C["Corrosion
attacks basin, fill, pipework
causes leaks and short life"]
    A --> D["Biofouling & Legionella
bacteria and algae
fouling + health risk"]
    B --> E["Control with:
LSI monitoring
Acid dosing / Antiscalant
Blowdown / COC control"]
    C --> F["Control with:
pH in correct range (7.0–8.5)
Corrosion inhibitor
Corrosion-resistant materials"]
    D --> G["Control with:
Oxidizing biocide (Cl/Br)
Non-oxidizing biocide
Drift eliminator
ASHRAE 188 WMP"]

5.1 Scaling — The Langelier Saturation Index (LSI)

LSI quantifies whether water tends to scale or corrode:

LSI = pH − pHs

where pHs is calculated from TDS, calcium hardness (Ca²⁺), total alkalinity, and temperature.

Scaling control measures:

• Blowdown: the most basic tool — discharge a controlled fraction of circulating water and replace with makeup, reducing COC.
• Acid dosing: H₂SO₄ or HCl reduces pH and alkalinity, driving pHs lower and thus lowering LSI. Requires a dosing pump with automatic pH controller.
• Antiscalant: synthetic polymers (phosphonates, polyacrylates) prevent CaCO3 crystal growth on fill surfaces and heat-exchanger tubes, enabling operation at higher COC without scale.

5.2 Corrosion — pH Balance and Inhibitors

• Maintain circulating-water pH in the 7.0–8.5 range (optimal for both scale and corrosion management).
• Use a corrosion inhibitor matched to the system's metallurgy: molybdate, silicate, zinc-based, or azole types for copper.
• Prevent chloride ion accumulation (aggressive toward steel and stainless) — manage COC and blowdown accordingly.
• Install corrosion coupons and inspect every 3 months to measure actual corrosion rates and validate inhibitor effectiveness.

5.3 Biofouling and Legionella — ASHRAE Standard 188

This is a life-safety issue, not merely a performance issue.

Why Legionella is dangerous in cooling towers:

• Circulating water at 25–45°C is the ideal growth range for Legionella pneumophila.
• Drift from the tower creates fine aerosols that can travel hundreds of metres and be inhaled directly into the lungs.
• Legionnaires' disease (severe pneumonia) carries a case-fatality rate of 5–30% in at-risk populations.
• Risk amplifiers include dead legs and stagnation in pipework, biofilm accumulation on fouled fill, organic loading in the water, and fluctuating temperatures.

ASHRAE Standard 188 requirements:

Biocides used for Legionella control:

Effective biocide strategy: alternate oxidizing and non-oxidizing biocides to prevent resistance and destroy biofilm together. Monitor chlorine residual continuously. Perform shock disinfection (hyperchlorination) before startup after a shutdown or when Legionella counts exceed threshold.

6. Fill Media — Select by Water Quality, Not Efficiency Alone

Fill is the medium that creates air-water contact area. It is central to thermal performance but also the primary site of fouling and Legionella colonisation.

For Thai plants using tap or borehole makeup water: film fill works well if a proper water treatment programme is maintained, but fill should be inspected every 6–12 months for biofilm and scale. If makeup water Total Suspended Solids (TSS) exceed 25 mg/L, consider pre-filtration or splash fill.

7. Materials — Match to Operating Environment

8. Acceptance Testing and CTI Certification

CTI (Cooling Technology Institute) is the global reference body for cooling-tower standards:

• CTI ATC-105: Acceptance Test Code defining the standard method for measuring thermal performance in the field — inlet/outlet temperature, wet-bulb temperature, flow rate, and heat rejection under controlled conditions.
• CTI STD-201: Certification standard for pre-delivery thermal performance — manufacturers with CTI-certified products publish reliable performance data that can be independently verified.

Best practices:

• Specify a thermal performance test per CTI ATC-105 on-site within 30–90 days of commissioning in the purchase contract.
• Require CTI-certified performance curves showing range/approach at WBT 28°C — not just a European rated condition.
• Include penalty provisions if the tower fails to meet contracted thermal performance.

9. Checklist to Ask Your Contractor / Supplier Before Signing

10. What Buyers Most Often Overlook

Test the wet-bulb at the actual installation point: do not assume WBT from regional tables alone. Some industrial sites — particularly those with nearby evaporative sources or enclosed courtyards — may experience local wet-bulb values higher than the area average. Verify with an on-site sling psychrometer or electronic WBT instrument before specifying.

Drift eliminators are a safety investment, not a cost: cutting costs on drift eliminator quality is never justified. Drift carrying Legionella that reaches people in the vicinity creates both a public-health risk and direct plant liability. A modern high-efficiency drift eliminator (≤ 0.002%) is inexpensive relative to the tower capital cost and the consequences of an outbreak.

Water treatment is an investment, not a cost: annual chemical treatment typically costs 0.5–2% of tower capital per year. Without a proper programme, fill fouls within 2–3 years, basin corrodes prematurely, and the entire tower may need replacement well before its design life — far more expensive than the treatment programme it replaced.

Cathodic protection for metallic components in aggressive water: cooling towers with hot-dip galvanised steel or carbon-steel basins in high-chloride or aggressive-water environments should consider cathodic protection for structural metallic components. See Cathodic Protection for Cooling Towers and Data Centers for a detailed treatment.

Test for Legionella before and after commissioning: do not wait for an outbreak. Establish a baseline Legionella test before the system enters service, then monitor on the schedule defined in the WMP per ASHRAE 188. Startup after a prolonged shutdown is a period of particularly elevated risk and warrants shock disinfection followed by confirmatory testing.

Basin drainage design matters: basins with dead zones or incomplete drainage allow sediment to accumulate and become a reservoir for Legionella colonisation. Proper basin slope toward a drain and correct drain-valve sizing reduce risk significantly and should be reviewed at the design stage.

Performance degrades as fill fouls: thermal performance drops noticeably when fill is as little as 20–30% blocked, and chiller COP follows. Inspect fill every 6 months, clean when fouled, and schedule fill replacement as part of the life-cycle maintenance plan.
