Welding Fire Blanket & Heat Insulation

Purpose & best fit

Woven fiberglass welding blanket for general MIG/TIG/Arc welding, abrasive cutting, and hot work permit scenarios where spatter < 760°C. Lay on floor, hang as curtain, or drape over flammable equipment. Class A spec range for typical light-spatter work (certifications sourced per project requirement).

Working principle

E-Glass fiber woven plain/leno blocks ignition via high melt point — 600-760°C sparks land and quench instantly without scorch, melt, or toxic smoke. Reusable 50-100 cycles when stored dry.

Specifications

Material

E-Glass fiberglass woven, uncoated

Continuous Temp

550°C

Peak Temp

600°C

Thickness

0.43 – 1.00 มม. / mm

Roll Width

1,000 มม. (custom cut ตามแบบ)

Roll Length

50 – 100 เมตร

Duty Grade

Light duty — สะเก็ดไฟเบา (เทียบเคียง Class A range)

Color

ขาวอมเหลือง / Off-white

Reuse Cycles

50–100 (จัดเก็บแห้ง / dry storage)

Purpose & best fit

High-Silica fabric (SiO₂ ≥ 96%) with vermiculite coating for heavy welding, plasma/oxy-fuel cutting, gouging, and slag splatter at 760-1,090°C. Tolerates direct flame exposure briefly. Primary choice for shipyards, pipeline construction, and heavy industry.

Working principle

Tightly-woven high-silica fibers + vermiculite (expandable mica mineral) coating that expands under high heat, forming an insulating layer preventing scorch. Vermiculite also reduces smoke and boosts flame retardancy beyond uncoated silica.

Specifications

Base Material

High-Silica (SiO₂ ≥ 96%)

Coating

Vermiculite — both sides

Continuous Temp

980°C

Peak Temp

1,200°C

Thickness

0.70 – 1.37 มม. / mm

Roll Width

920 มม. (custom cut)

Roll Length

50 เมตร

Duty Grade

Heavy duty — slag + light molten (เทียบเคียง Class B range)

Color

น้ำตาลทอง / Tan-gold (vermiculite)

Reuse Cycles

30–50

Purpose & best fit

Fiberglass cloth with double-sided silicone coating (translucent orange/dark-green/yellow) used as welding bay curtains — filters UV arc-flash radiation + blocks spatter simultaneously. Long-life because silicone prevents fiber shedding; smooth, non-irritating surface for operators in frequent contact.

Working principle

Silicone elastomer fully encapsulates fiberglass fabric on both sides — operators can handle, roll, hang it without itchy fiber dust. Translucent colors filter UV (280-400 nm) from welding arcs while passing enough visible light for supervisor visibility. Withstands spatter ≤ 500°C.

Specifications

Base Material

E-Glass fiberglass woven

Coating

Silicone — both sides (double-coated)

Working Temp

≤ 500°C

Thickness

0.45 – 0.90 มม. / mm

Roll Width

1,500 มม.

Roll Length

50 เมตร

Duty Grade

Light duty + UV filter (เทียบเคียง Class A range)

Color (translucent)

ส้ม / เขียวเข้ม / เหลือง

UV Filter

280–400 nm arc-flash radiation

Hardware

Eyelet + chain + ราว track พร้อมรอบติดตั้ง

Purpose & best fit

Aluminosilicate ceramic fiber blanket — highest temperature rating in the welding blanket family. For molten metal splash, foundry operations, billet/ingot quenching, forge work, and hot work permits with slag > 1,090°C. Floor cover during metal pouring + billet drape during transport.

Working principle

Aluminosilicate ceramic fibers (Al₂O₃ 45-50% + SiO₂ 50-55%) — refractory rated to 1,260°C continuous. Fiber structure traps air → low thermal conductivity → slow heat transfer. Chemically inert against most molten steel/aluminum/copper.

Specifications

Material

Aluminosilicate ceramic fiber (Al₂O₃ 45-50% + SiO₂ 50-55%)

Continuous Temp

1,260°C (1260-grade)

Peak Temp

1,430°C (HZ grade option)

Thickness

3 – 25 มม. (5/10/15/25 mm มาตรฐาน)

Density

96 – 160 kg/m³

Roll Width

1,000 มม.

Duty Grade

Foundry / heavy molten (เทียบเคียง Class C range)

Color

ขาวงาช้าง / Off-white

Reinforcement (option)

Wire-mesh, glass-cloth backing

Reuse Cycles

10–20 (ขึ้นกับ molten exposure)
