Which Engine Oil Grade for the Hilux Revo — 5W-30 / 10W-30 / 15W-40 + ZIC Pricing

TL;DR — Which Engine Oil Grade for the Hilux Revo?

Full technical comparison of the 3 grades (cold-start, HTHS, API/ACEA, OEM mapping) → /compare/engine-oil-5w30-vs-10w30-vs-15w40

Why the Hilux Revo (1GD-FTV / 2GD-FTV) Must Use 5W-30 Low-SAPS

Every Hilux Revo from 2015 onward (Rocco, Prerunner, Smart Cab, Standard Cab) uses the 1GD-FTV (2.4L) or 2GD-FTV (2.8L) engine, which has:

• DPF (Diesel Particulate Filter) — captures soot from the exhaust → requires regeneration every 200-500 km
• EGR (Exhaust Gas Recirculation) — reduces NOx
• Common Rail Direct Injection — injector pressure > 2,000 bar
• Euro 4-5 compliance — sulphur diesel ≤ 50 ppm

What Is Low-SAPS, and Why Is It Required?

SAPS = Sulphated Ash, Phosphorus, Sulphur — components in the additive package of engine oil:

Full-SAPS engine oils (generic 15W-40 + API CK-4 mineral) cause:

• DPF clogging within 20,000-40,000 km (a DPF normally lasts 150,000+ km)
• Toyota DPF replacement cost ~฿80,000-150,000
• Catalytic converter degrading 30-50% faster

→ ACEA C3 or DPF-safe oil is mandatory for the Hilux Revo 2015+

SAE J300 — Why 5W-30 Is Better Than 10W-30 in the Hilux Revo

Why Not Use 15W-40 in the Hilux Revo?

Even though Bangkok morning temperatures of 22-28°C are not sub-zero — other reasons to avoid it:

1. HTHS too high → fuel consumption rises 3-5%
2. Bearing clearance of the 1GD-FTV is designed for low-viscosity (5W-30) — 15W-40 is too thick to reach the piston rings
3. DPF + EGR → most 15W-40 mineral oils are full-SAPS → violate the ACEA C3 spec
4. Warranty void — Toyota will deny warranty if oil that doesn't match the manual spec is used

Drain Interval — How Often to Change the Oil

flowchart LR
    Start[Hilux Revo
Service Reminder] --> Type{Usage type}
    Type -->|City stop-go BKK| Severe[Severe Duty]
    Type -->|Highway long-haul| Normal[Normal Duty]
    Type -->|4WD off-road / heavy load| Severe
    Severe --> S1[Synthetic: 7,500 km]
    Severe --> S2[Semi-synth: 5,000 km]
    Normal --> N1[Synthetic: 10,000-15,000 km]
    Normal --> N2[Semi-synth: 8,000-10,000 km]
    S1 --> Filter[Replace Toyota 90915-YZZJ3 filter]
    S2 --> Filter
    N1 --> Filter
    N2 --> Filter

Severe Duty in Thailand — Which Cases?

Per Toyota Owner's Manual section 9 (Maintenance Schedule):

• Driving in Bangkok / Pattaya stop-go traffic for over 50% of the distance
• Driving in a dust environment (construction, sandbar, plantation)
• 4WD heavy load — towing a trailer > 1,500 kg, off-road
• Long engine idling — taxi, delivery, courier vehicles that stop frequently
• Short distances — engine doesn't reach full warm-up (engine < 80°C)

Most Thai factories + pickup fleets → fall under Severe Duty → change every 7,500 km

ZIC Pricing for the Hilux Revo — Through Sahawatthanakit

Hilux Revo engine oil capacity:

ZIC X-9000 5W-30 ACEA C3 (Recommended for Hilux Revo)

• Grade: Fully synthetic, ACEA C3, API SP/CK-4
• DPF compatible: ✓
• Drain interval: up to 15,000 km (normal duty)
• ZIC X-9000 price (4L box): ฿1,100-1,400
• One change for Hilux Revo 2.4/2.8 = 2 boxes = ฿2,200-2,800 + oil filter ฿250-450
• Annual cost (3 changes/year severe duty) = ฿7,500-9,800

ZIC X7 10W-30 API SP (Old Hilux Vigo + 2.7 petrol)

• Grade: Semi-synthetic, API SP/CK-4
• DPF compatible: ACEA C3 not required — usable with Hilux Vigo pre-2015 + 2.7 petrol
• Drain interval: 8,000-10,000 km
• Price (4L box): ฿700-950
• One change = 2 boxes = ฿1,400-1,900

ZIC TOP 7000 15W-40 API CK-4 (Hilux Vigo + Large Fleet Vehicles)

• Grade: Mineral / part-synth blend, API CK-4 (heavy diesel)
• DPF compatible: ✗ Do not use with the Revo (Euro 4-5)
• Drain interval: 10,000-15,000 km (Vigo + commercial pre-2015)
• 18L pail price: ฿3,000-3,800 (enough for 2-3 changes)
• 200L drum price: ฿28,000-34,000 (fleet of 30+ vehicles)

Toyota OEM Engine Oil Filters

Advice for Fleet Managers — Saha Regular Customers

If you have 10+ Hilux + commercial pickups:

1. Use ZIC X-9000 5W-30 C3 on every new-generation Revo (2015+) — DPF + warranty
2. Use ZIC X7 10W-30 on pre-2015 Vigo + 2.7 petrol — 30-40% cheaper than X-9000
3. Net 30 account — credit can be opened for regular customers (mid-month invoice)
4. Filters bundled — order together with oil, same lead time
5. COA + TDS — every batch comes with an attached certificate of analysis — used in ISO 9001 audit + insurance

Request a quote based on your fleet size + the Hilux models you run at /quote?service=lubricant — the team replies within 2 hours.

Conclusion — Decide in 30 Seconds

flowchart TD
    Start[Which Hilux do you have?] --> Q1{Year 2015 or later?}
    Q1 -->|Yes, Revo| Q2{Fuel type?}
    Q2 -->|Diesel 2.4 / 2.8| Diesel[ZIC X-9000 5W-30 ACEA C3
~฿2,200-2,800 per change]
    Q2 -->|petrol 2.7| Petrol[ZIC X-9000 5W-30
or X7 5W-30
~฿1,400-2,200 per change]
    Q1 -->|No, Vigo+| Q3{Heavy usage?}
    Q3 -->|Fleet / commercial| Heavy[ZIC TOP 7000 15W-40
~฿3,000-3,800 per 18L]
    Q3 -->|Personal| Light[ZIC X7 10W-30
~฿1,400-1,900 per change]
    Diesel --> Quote
    Petrol --> Quote
    Heavy --> Quote
    Light --> Quote
    Quote[Request a Saha quote — reply within 2 hours]

Quick reference card

• Hilux Revo 2.4 / 2.8 (post-2015): ZIC X-9000 5W-30 ACEA C3 → DPF-safe, fully synthetic
• Hilux 2.7 petrol: ZIC X-9000 or ZIC X7 5W-30
• Hilux Vigo 3.0 (pre-2015): ZIC X7 10W-30 or ZIC TOP 7000 15W-40 (if fleet)
• Change at 7,500 km (severe duty BKK) or 10,000 km (highway)
• Toyota 90915-YZZJ3 filter every time
• Cost per change ฿1,400-2,800 + filter ฿250-450
