Calculate the ROI of switching from DOL to a VFD for 5.5-200 kW motors in Thai factories — IEC vs NEC capex, annual energy savings, 1-3 year payback + IEC 61800-9 + harmonic mitigation.
Why VFD ROI matters
Three-phase motors in a Thai factory draw 60-70% of the whole plant's electricity. Most are still DOL (Direct-On-Line) starters, which:
- Run at full speed all the time (no load matching)
- Pull 6-8× full-load starting current
- Wear out the motor + driven machine
- Use a throttle/valve/damper to control flow = wasted energy
A VFD (Variable Frequency Drive) varies the supply frequency → the motor speed matches the load. The results:
- Pump + Fan: save 30-50% (affinity laws — power ∝ speed³)
- Conveyor + Mixer: save 10-20% (constant-torque load)
- Soft start reduces stress on motor + bearings + gearbox
- Power factor correction integrated
Quick payback calculation
The simple formulas:
Annual savings (THB) = Motor kW × hr/year × THB/kWh × savings %
Payback (yr) = VFD capex (THB) / Annual savings (THB)
Example — a 75 kW pump at a cement plant, 16 hr/day × 300 day/yr = 4,800 hr/yr:
| Item | Value |
|---|---|
| Motor power | 75 kW |
| Operating hours/year | 4,800 |
| Electricity (EGAT/MEA TOU peak) | ฿4.50/kWh |
| Annual energy without VFD | 75 × 4,800 = 360,000 kWh = ฿1,620,000 |
| VFD savings (pump, affinity laws) | 40% typical |
| Annual savings | 360,000 × 0.40 × 4.50 = ฿648,000 |
| VFD 90 kW capex (ABB ACS580 / Schneider Altivar) | ฿180,000 |
| Installation + commissioning | ฿40,000 |
| Payback | 220,000 / 648,000 = 0.34 yr (4 months) |
10-year NPV @ 8% discount = ~฿4.1M cumulative savings.
graph TD
Start[75 kW pump motor
DOL today] --> Current[Annual energy ฿1.62M
4,800 hr/yr]
Current --> Add[Add VFD ฿220K total]
Add --> Savings[Annual savings ฿648K
40% reduction]
Savings --> Payback[Payback 4 months
10-yr NPV ฿4.1M]
style Payback fill:#10b981,color:#fffWhen a VFD pays off best
Best ROI applications:
- Centrifugal pump + fan — power ∝ speed³ (affinity laws) — 30-50% savings
- HVAC variable air volume — chilled-water pump + supply fan — 25-45%
- Screw + reciprocating compressors — 15-30%
- Cooling tower fan — 30-50%
Marginal ROI:
- Constant-speed conveyor + mixer + crusher — 5-15% (mostly from soft-start wear reduction)
- Motors < 5.5 kW — VFD capex not worth it
Do NOT use a VFD:
- Submersible pump motor (cable run > 50 m causes insulation pulse damage)
- Old motor < class F insulation (VFD common-mode voltage damages bearings)
- Hazardous-area motor (needs an IEC 60079 explosion-proof VFD)
Capex reference (May 2026)
| Motor kW | DOL contactor capex | VFD capex (ABB/Schneider/Siemens) | Soft starter capex |
|---|---|---|---|
| 7.5 | ฿5K | ฿35-55K | ฿15-25K |
| 22 | ฿12K | ฿70-110K | ฿40-65K |
| 75 | ฿35K | ฿160-220K | ฿110-160K |
| 150 | ฿60K | ฿300-450K | ฿220-330K |
| 200 | ฿80K | ฿380-550K | ฿290-420K |
Add installation ฿20-80K + commissioning ฿15-40K depending on size + harmonic filter requirement.
Harmonic mitigation — critical when feeding from EGAT/MEA/PEA
A VFD generates harmonic currents at the 5th, 7th, 11th, and 13th orders. Under IEC 61000-3-12 + IEEE 519-2014 + the EGAT/MEA grid code, THD must be < 5% at the Point of Common Coupling.
Solutions:
- Built-in DC reactor — THD ~30-40% (basic VFD)
- 5% AC line reactor — THD ~25-30%
- Passive harmonic filter — THD ~8-12%
- Active harmonic filter — THD ~3-5% (premium)
- 12-pulse / 18-pulse VFD — THD ~10% / ~5% (for large 200 kW+ multi-drive systems)
Factories fed by MEA/PEA must measure THD before adding any new VFD above 100 kW. The Saha team includes the measurement + filter sizing in the quote.
Decision: VFD vs Soft Starter vs DOL
These three are the systems most commonly seen in a Thai factory. For a more detailed comparison:
- /compare/vfd-vs-soft-starter-vs-dol-motor-control — control technique comparison
- /compare/plc-vs-dcs-vs-scada-factory-automation — automation context
Or run your own savings estimate at /tools/motor-vfd-sizing-calculator.
Saha Service
Saha supplies + installs VFDs end to end:
- Brands: ABB ACS580/ACS880, Schneider Altivar 320/630/930, Siemens Sinamics G120/V20, Mitsubishi FR-E700/A800
- Sizing: capacity + harmonic filter + EMC + reactor design per IEC 61800-9
- Installation: wiring + commissioning + on-site parameter tuning
- Energy audit: baseline measurement + verified savings 30-90 days after commissioning
- Service contract: spare parts + 24/7 remote support
Send your motor spec (kW, RPM, load profile) + operating hours/year + electricity rate → we calculate the ROI + quote within 48 hours.
