The split-AC market in Thailand has shifted. Units manufactured after 2019 mostly use R32 instead of R410a, which dominated since 2002. The driver is global environmental regulation (Kigali Amendment, ratified by Thailand in 2019) and a Global Warming Potential (GWP) that R32 cuts by roughly 3× compared to R410a.
But many Thai factories and buildings still run R410a systems installed years ago, raising a recurring question among service teams: "How long can the existing R410a system be repaired economically?" and "If we're replacing units, is R32 really the better choice?"
Technical comparison
| Property | R410a | R32 |
|---|---|---|
| ASHRAE / ISO 817 Class | A1 (non-flammable, non-toxic) | A2L (mildly flammable, non-toxic) |
| GWP (100-yr, IPCC AR5) | 2,088 | 675 |
| Composition | Blend (R32 + R125, 50:50) | Pure single-component (CH₂F₂) |
| Boiling point @ 1 atm | -51.6°C (azeotrope) | -51.7°C |
| Critical temperature | 71.4°C | 78.1°C |
| Discharge pressure (relative) | baseline | ~30% higher |
| Mass charge for same duty | baseline | ~20-25% less |
| Compressor lubricant | POE | POE (different grade) |
| Price per kg (Thailand, 2026) | ~700-900 THB | ~1,200-1,500 THB |
| Used in | AC / chillers manufactured ~2002-2019 | New split AC from Daikin / Mitsubishi / Panasonic / Hitachi (2019+) |
R32 is literally one component of R410a — R410a is a 50/50 blend of R32 and R125. When the industry decided to cut GWP, the fastest path was to drop R125 (whose own GWP is around 3,500) and use R32 alone.
Why you cannot swap one for the other
flowchart TD
Start{"What system is on site"}
Start -->|"Older R410a system
(2002-2019)"| R410["R410a system
• A1 non-flammable
• Blend (R32 + R125)
• Compressor + EXV
designed for blend pressure"]
Start -->|"New R32 system
(2019+)"| R32["R32 system
• A2L mildly flammable
• Pure single
• Smaller charge
• Leak sensor required"]
R410 -.X.-> Mix{"⚠️ Never charge R32
into R410a system"}
R32 -.X.-> Mix
Mix --> Failure["• Discharge pressure exceeds spec
• Compressor coil overheats by 30%
• POE oil grade mismatch
• Service ports incompatible
• Pressure relief misbehaves"]Never charge R32 into a system designed for R410a. Engineering reasons:
- Discharge pressure ~30% higher at the same operating temperature — R410a-spec compressors run beyond design envelope, pressure relief may trip or seals fail.
- Pressure relief valves and tubing in R410a systems are sized to R410a's pressure (per EN 378). R32's higher pressure pushes them past fatigue limits over time.
- Compressor oil grade — both systems use POE, but the POE grade differs because R32 has reduced miscibility with some POE formulas vs. R410a.
- Service ports — R32 historically used the same 5/16" port as R410a, but some manufacturers are introducing mechanical anti-cross-charging features.
- Refrigerant leak sensor — A2L systems (R32) require a leak sensor per IEC 60335-2-40. There's nowhere to install it on an R410a chassis.
A2L Class — what HVAC technicians need to know
A2L = Lower Flammability under ASHRAE Standard 34 / ISO 817 means:
- LFL (Lower Flammability Limit) between 3.5–10% by volume in air
- Burning velocity ≤ 10 cm/s
- Ignition requires sustained contact with ≥ 1300°C flame (e.g., oxy-fuel torch)
Comparison with other refrigerants:
| Refrigerant | ASHRAE class | Flammability |
|---|---|---|
| R134a / R410a | A1 | Non-flammable at any concentration in air |
| R32 / R1234yf | A2L | Very low; needs > 1300°C ignition source |
| R290 (Propane) | A3 | Highly flammable, like LPG |
| R600a (Isobutane) | A3 | Highly flammable, like LPG |
Practical guidance for technicians working on R32:
- No smoking or open flame near a vent that has just been opened — momentary concentration may reach LFL.
- Ventilate during purge or recovery — never perform in a closed room without airflow.
- Recovery equipment must have spark-proof motor or be A2L-certified. Most R410a recovery machines work, but verify rating before use.
- Room size — IEC 60335-2-40 specifies minimum room area by R32 charge mass (e.g., a 12,000 BTU unit with ~900g R32 needs a room ≥ 4.6 m²).
- Brazing with oxy-fuel — purge the system with OFN (Oxygen-Free Nitrogen) before opening any flame, same as R410a but enforced more strictly.
Efficiency and energy bill
R32 typically delivers 5-10% higher COP than R410a at the same rated condition, because:
- Lower mass flow → less pumping loss
- Higher critical temperature (78.1°C vs 71.4°C) → stays in sub-critical operation longer in hot weather
- Higher heat capacity per kg (~20% higher)
In Thailand's typical 35-40°C ambient, R32 has a larger efficiency advantage than in cooler climates, translating to an 8-12% lower electricity bill across the unit's life vs. an equivalent R410a unit (manufacturer data: Daikin, Mitsubishi).
TIS 2580-2562 (the Thai Industrial Standard for split AC efficiency) sets minimum SEER for new units sold in Thailand. R32 units more easily reach 5-star SEER (≥ 21), while older R410a designs typically land at 3-4 stars.
Decision guidance for Thai facilities and buildings
Existing R410a systems
| Situation | Recommendation |
|---|---|
| Compressor in good shape, 3-7 yrs old | Keep maintaining — top-up charging is routine; refrigerant price is stable |
| Compressor failed and needs replacement | Run TCO calculation — replacement compressor + new refrigerant ≈ 50% of a new R32 unit. Factor annual energy savings |
| Coil leaking, multiple repairs needed | Replace with new R32 unit — R410a coils average 7-10 years lifespan |
| System older than 12 years | Full replacement — efficiency typically drops 25-40% from new |
New installations
Default to R32, because:
- Long-term supply — R410a production quotas are starting to ratchet down in China / Japan / Thailand by 2027. Prices likely rise.
- F-gas regulation — Europe banned R410a in new equipment from 2023; global manufacturers are phasing R410a out of their lineup.
- Better efficiency — 8-12% lower energy bill as noted.
- Smaller charge — any future refrigerant tax pays less per unit.
For large commercial chillers (> 100 ton), the next-generation choice is shifting to R454B (GWP 466) or R32-based low-GWP blends. R410a in chillers will phase out gradually after 2027.
Constraints to manage
- Technician retraining — recovery / vacuum / leak-detection tools must be A2L-rated. Thailand's Department of Alternative Energy Development and the Refrigeration Engineers Association are starting certification courses.
- Small mechanical rooms — IEC 60335-2-40 minimum-area rules can make "large unit in a small room" non-compliant for R32 — use R454B or central chiller instead.
- Importer/distributor license — refrigerants fall under Thailand's Hazardous Substances Act. Source only from licensed importers (Sahawatthanakit holds the required license).
Bottom line
New install: R32 — better efficiency, regulation-aligned, supply secure long-term.
Existing R410a: Keep maintaining as normal. Never cross-charge with R32. Plan replacement when compressor or major coil fails.
For technicians: Enroll in A2L handling certification — Thai law does not yet mandate an A2L-specific license, but several manufacturers now require certification for warranty service.
On the supply side, Sahawatthanakit (1988) carries both R32 and R410a imported directly through Freon (Dupont) and ORAFON, with MSDS and certificate of analysis ready for government tenders and factory QA work.
